5Pin connector male insert HA-004-M IP65 protection degree,Heavy duty industrial connector

Product Categories

Wellmade IND. Manufacturing(HK) Ltd

Contact Now

Model Number : HA-004-M

Place of Origin : China

MOQ : 1PCS

Payment Terms : T/T

Supply Ability : 1000PCS

Delivery Time : 1-5 working days

Packaging Details : Carton Box

Number of contacts : 5

Rated current : 10A

Working voltage : 230/400V

Contact Now

5Pin connector male insert HA-004-M IP65 protection

5Pin Male Insert Parameter:

Inserts
Number of contacts	4+PE
Electrical data acc. to EN 61 984
---Rated current	10A
---Rated voltage conductor	230/400V
---Rated impulse voltage	4kV
---Pollution degree	3
---or	10A 250V 4kV 3
Rated voltage acc. to UL	600V
Insulation resistance	≥10¹⁰Ω
Material	polycarbonate
Limiting temperatures	-40℃...+125℃
Flammability acc. to UL 94	V0
Mechanical working life(mating cycles)	≥500
Contacts
Material	copper alloy
Surface	hard-gold plated
Surface	hard-silver plated
Contact resistance	≤1mΩ
Spring terminal
---Wrie gauge	0.14-2.5mm²
---AWG	26-14

5Pin connector male insert HA-004-M IP65 protection degree,Heavy duty industrial connector

More information, please contact us anytime!

5Pin connector male insert HA-004-M IP65 protection degree,Heavy duty industrial connector Images
